Compressor Applications

Make Compressors Great Again!

Innovation high-tech oil free booster compressor for high pressure applications

What can our compressors do?

Water is a source of energy and well-being and it’s the means used by Idrocomp booster technology for high-pressure compression of technical gases. This kind of technology is used in various sectors, such as on oil platforms, to refill oxygen tanks with breathable air or gas mixture in scuba diving, or to refill gas tanks for food or medical purposes.

Idrocomp company has designed the oil-free booster to respond to the need for the compression of gases coming from generators or compressors with min 1 bar to max 210 bar pressure and the refill of bottles without changing the chemical characteristics of the gas or gas mixture.

Technologies & Features

220 BAR MAX PRESSURE

Water and Air cooled system

BOOSTER OIL FREE

Minimum Maintenance

CLASS IE2 ELECTRIC MOTORS

Entirely stainless steel

Low electricity consumption

Totally recyclable compressors

Best quality hydraulic and electric components

Assembled with love in the European Union
with the highest quality standards

Our customers say

Andrea Donati,
CEO at Ponza Diving Center, Italy

“I purchased this revolutionary Minibooster compressor for transferring high pressure oxygen and I must say that it does its job very well, never had problems and at the time of maintenance. I received excellent fast and efficient assistance. I am very proud of this Idrocomp compressor.”

Technical Data

The following technical table identifies some examples of compressor sizes indicating high pressure air or compressed gas flow from Idrocomp compressors, moreover GasTechno company is available to determine the booster for the most demanding customers

Booster Model Max Pressure
Outlet (Bar–Psi)
Flow @ 50
Bar Inlet (Nl/min)
Power supply (Volt) Electric power
installed (Kw)
Step maint.
gasket sealings (Years)
Dimensions W x L x H
MB MCS 15 210 - 3045 350 220 (at 50 Hz) 2.2 5 900 x 400 x 400 (mm)
MB MCS 13 210 - 3045 350 120 (at 60 Hz) 2.2 5 35.5 x 15.75 x 15.75 (“)
Booster Model Max Pressure
Outlet (Bar–Psi)
Flow @ 10
Bar Inlet (Nl/min)
Power supply
50 Hz – 3 ph (Volt)
Electric power
installed (Kw)
Step maint.
gasket sealings (Years)
Dimensions W x L x H (mm)
BCMS 15 210 - 3045 150 380 4 5 1300 x 600 x 500
4CMS 15 210 - 3045 320 380 8 5 1300 x 700 x 600

Unique design and technology

CE PED Certification gas group I & II
2014/68/EU (formerly 97/23/EC) Certified
Certification of manufacturers or assemblers in accordance with ASME Boiler and Pressure Vessel Code (BPVC) — Section VIII Division Il
